MTD 807 - Page 31

31
Models 807 & 808
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
REF.
NO.
PART
NO. DESCRIPTION
1 683-0195 Bracket Assembly (8-style)
2 710-0599 Self-tapping Screw, 1/4-20 x .5
3 710-0751 Hex Cap Screw, 1/4-20 x .62
4 710-0924 Phillips Pan Screw, 1/4-20 x .75
5 710-1017 Truss Phillips Screw, 1/4-20 x .625
6 710-1268 Screw, #10-16 x .375
7 710-0376 Hex Cap Screw, 5/16-18 x 1.0
8 712-0271 Hex Sems Nut, 1/4-20
9 712-0292 U-type Speed Nut, 1/4-20
10 712-0431 Flange Lock Nut, 3/8-16
11 726-0211 U-nut, 5/16-18
12 726-0293 Retainer Nut, 3/8
13 731-1854A Headlight Lens (8-style)
14 735-0126 Rubber Washer, .87 x .33
15 736-3036 Flat Washer, .406 x 1.5 x 11GA
16 746-1085 Choke Knob/Cable
(Models with either B&S Twin)
746-1088 Choke Knob/Cable
(Models with Kohler)
17 783-0475A LH Side Panel (8-style)
18 783-0476B RH Side Panel (8-style)
19 783-0477A Grill (8-style)
20 783-0478A Hood (8-style)
21 783-1309 Hood Hinge Bracket
22 783-0553A Hood Support Bracket
23 710-0604A Self-tapping Screw, 5/16-18 x .625
24 751-0658B Fuel Tank, Three Gallon
751-0659A Fuel Tank, Two Gallon (Shown)
25 751-0603 Fuel Cap (Fits Either Tank)
26 710-0809 Self-tapping Screw, 1/4-20 x 1.25
27 710-0895 Self-tapping Screw, 1/4-15 x .75
28 710-3217 Truss Phillips Screw, #8-32 x .375
29 712-0142 Hex Nut, #8-32
30 731-1857 Throttle Control Knob
31 731-2225C Dash Panel (Models w/ Electric PTO)
731-2122C Dash Panel (Models w/ Manual PTO)
32 731-2226 Cruise Control Button
731-2228 Cruise Cover (Models w/o Cruise Control)
33 731-2227 Parking Brake Button
34 736-0142 Flat Washer, 9/32 x 1/2 x 1/16
35 747-1196 Brake/Cruise Pivot Rod
36 749-1087A Dash Support Tube
37 747-1184 Hood Plenum Support Rod
38 731-2247A Hood Plenum
(Models with B&S OHV V-Twin)
731-2248 Hood Plenum
(Models with B&S Opposed Twin)
N/A Hood Plenum
(Models with Kohler)
39 726-3046 Ratchet Clip
40 725-1752 Electric PTO Switch
41 712-3027 Hex Flange Lock Nut, 1/4-20
42 736-3078 Flat Washer, .349 x 1.0 x .063
43 710-1238 Screw, 5/16-18 x .875 (Grade 5)
44 712-3004A Hex Nut, 5/16-18
45 747-1215A Hood Latch
46 712-0272 Hex Sems Nut, #10-32
47 710-0473 Machine Screw, #10-24
48 625-0051 Headlight Assembly
49 710-0896 Hex Index Washer Screw, 1/4-14 x .0625
50 735-0199A Rubber Bumper
51 725-1745 Ignition Key w/ plastic cover
725-1744 Ignition Key w/o plastic cover
52 725-1741 Ignition Switch
53 725-1976 Systems Indicator Monitor w/ Hour Meter
725-1758 Systems Indicator Monitor w/ Ammeter
58 711-0332 Clevis Pin, .50 x .78
59 768-0010A Bumper Assembly
60 714-0145 Internal Cotter Pin
61 731-2300 Hood, Red (7-Style)
731-2301 Hood, Green (7-Style)
731-2302 Hood, Black (7-Style)
731-2303 Hood, Charcoal Grey (7-Style)
62 731-2306 Hood Plenum
63 783-1034 Hood Bracket (7-Style)
64 783-1495 Hood Side Bracket (7-Style)
— 629-0309 Headlight Wire Harness
629-1067 Tractor Wire Harness
(Models with Hour Meter & Electric PTO)
629-1068 Tractor Wire Harness
(Models with Ammeter & Electric PTO)
— 629-1071 Tractor Wire Harness
(Models with Hour Meter & Manual PTO)
— 629-1072 Tractor Wire Harness
(Models with Ammeter & Manual PTO)
REF.
NO.
PART
NO. DESCRIPTION
