41
IMPORTANT: For a proper
working machine, use
Factory Approved Parts.
V-belts are designed to
engage and disengage
safely. A substitute (non
OEM) V-belt can be
dangerous by not
disengaging completely.
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
Models 807 & 808
REF.
NO.
PART
NO. DESCRIPTION
1 783-0653E Steering Support Bracket
2 754-0476 PTO Belt (Models w/ 46-inch Deck)
N/A PTO Belt (Models w/ 54-inch Deck)
3a 717-1709 Electric PTO Clutch (Models w/ 46-inch Deck)
3b 717-1774 Electric PTO Clutch (Models w/ 54-inch Deck)
4a 783-1003 PTO Clutch Anti-rotation Bracket (Models w/ 46-inch Deck)
4b 783-1487 PTO Clutch Anti-rotation Bracket (Models w/ 54-inch Deck)
5 710-0859 Hex Cap Screw, 3/8-16 x 2.5
6 710-1238 Hex Head Washer Screw, 5/16-18 x .875
7 712-0431 Flange Lock Nut, 3/8-16
8 732-0978 Extension Spring, .62 x 5.62
9 712-3004A Flange Lock Nut, 5/16-18
10 710-3180 Hex Cap Screw, 5/16-18 x 1.75
11 712-3010 Hex Nut, 5/16-18
12 683-0294 Idler Bracket Assembly
13 738-3056 Shoulder Screw, 1/2 x 2.5
14 710-3144 Hex Cap Screw, 3/8-16 x 2.0
15 710-3025 Hex Cap Screw, 5/16-18 x .625
16 738-0785 Shoulder Spacer, 1.38 x .445 x .36
17 736-0171 Lock Washer, 7/16
18 710-3157 Hex Cap Screw, 7/16-20 x 3.25 (Grade 5)
19 725-1706 12-volt Battery, 270 CCA
20 710-0751 Hex Cap Screw, 1/4-20 x .62
21 712-0271 Hex Sems Nut, 1/4-20
22 712-3087 Wing Nut, 1/4-20
23 725-1426 Solenoid, 12-Volt, 100 Amp
24 710-0599 Self Tapping Screw, 1/4-20 x .5
25 736-0222 Lock Washer, 1/4
26 783-1033A Hitch Plate
27 748-0415B Spacer, 3/8 x 1.54
28 756-0627B Idler Pulley, 3.5
29 783-0349 Battery Tray
30 712-0459 Flange Lock Nut, 7/16-20
31 783-0891B Deck Stop
32 710-0604A Self Tapping Screw, 5/16-18 x .625
33 732-3080 Compression Spring, 1.28 x 3.5
34 723-0444 Battery Strap
35 738-1020 Shoulder Screw, .625 x .5, 7/16-20
36 736-0407 Bell Washer, .45 x 1.0 x .062
37 738-1132 Shoulder Screw, 1/4-20, .25 x .15
38 736-0322 Flat Washer, .45 x 1.25 x .164
