MTD 807 - Page 43

43
REF.
NO.
PART
NO. DESCRIPTION
1 647-0064 PTO Engagement Lever Assembly
2 747-1243 Belt Keeper Rod
3 710-0276 Carriage Screw, 5/16-18 x 1.00
4 712-0431 Flange Lock Nut, 3/8-16
5 710-0831 Hex Cap Screw, 3/8-16 x 5.5
6 710-1238 Hex Head Washer Screw, 5/16-18 x .875
7 712-0229 Push Nut, 3/8
8 754-0487 PTO Belt (Models w/ 46-inch deck)
N/A PTO Belt (Models w/ 54-inch deck)
9 712-3004A Flange Lock Nut, 5/16-18
10 712-3010 Hex Nut, 5/16-18
11 714-0470 Cotter Pin, 1/8 x 1.25
12 726-0201 Speed Nut, .3125
13 731-2111A PTO Knob
14 683-0438 PTO Engagement Plate Assembly
15 732-0991A Belt Guard
16 736-0108 Flat Washer, .510 x .750 x .033
17 736-0119 Lock Washer, 5/16
18 736-0140 Flat Washer, .385 x .62 x .063
19 736-0275 Flat Washer, 5/16
20 736-0300 Flat Washer, .406 x .875 x .059
21 736-0331 Bell Washer, .39 x 1.13 x .062
22 736-3010 Flat Washer, .407 x .812 x .135
23 738-0372A Shoulder Spacer, .380
24 741-0708 Hex Split Flange Bearing, .5
25 747-1112D PTO Engagement Handle
26 747-1286 Belt Keeper Rod
27 748-0415A Spacer, 3/8 x 1.54
28 756-0627B Idler Pulley, 3.5
29 710-0347 Hex Cap Screw, 3/8-16 x 1.75
30 783-0744A Engagement Stop
31 783-0891B Deck Stop
32 710-0604A Self Tapping Screw, 5/16-18 x .625
33 732-3080 Compression Spring, 1.28 x 3.5
34 723-0444 Battery Strap
35 738-1020 Shoulder Screw, .625 x .5, 7/16-20
36 736-0407 Bell Washer, .45 x 1.0 x .062
37 712-0459 Flange Lock Nut, 7/16-20
38 783-1031A Hitch Plate
39 783-0349 Battery Tray
40 725-1426 Solenoid, 12-Volt, 100 Amp
41 710-0599 Self Tapping Screw, 1/4-20 x .5
42 736-0222 Lock Washer, 1/4
43 683-0304 Lower Frame Assembly
44 725-1706 12-volt Battery, 270 CCA
45 710-0751 Hex Cap Screw, 1/4-20 x .62
46 712-0271 Hex Sems Nut, 1/4-20
47 712-3044 Wing Nut, 1/4-20
48 732-1165 Extension Spring, .50 x 5.0
49 710-3180 Hex Cap Screw, 5/16-18 x 1.75
50 750-0596 Spacer Cup
51 710-3029 Hex Head Cap Screw, 7/16-20 x 1.25
52 736-0171 Lock Washer, 7/16
53 736-0322 Flat Washer, .450 x 1.25
54 756-0982B Engine Pulley, 3.56 OD x 5.56
55 732-0944 Extension Spring, .75 x 6.75
56 783-0653E Steering Support Bracket
57 732-1013 Belt Guard
REF.
NO.
PART
NO. DESCRIPTION
Models 807 & 808
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
IMPORTANT: For a proper
working machine, use
Factory Approved Parts.
V-belts are designed to
engage and disengage
safely. A substitute (non
OEM) V-belt can be
dangerous by not
disengaging completely.
