MTD 807 - Page 47

47
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
IMPORTANT: For a proper
working machine, use
Factory Approved Parts.
V-belts are designed to
engage and disengage
safely. A substitute (non
OEM) V-belt can be
dangerous by not
disengaging completely.
Models 807 & 808
REF.
NO.
PART
NO. DESCRIPTION
1 12650 Bracket, Adjustment, Height
2 16606 Bracket, Hook, Retainer
3 618-0671 Spindle Assembly, Pulley, 5.39 Dia x .5625
4 683-0254 Bracket Assembly, Deck, Hanger LH
5 683-0459 Idlr Assembly, 54"
6 683-0608 Bracket Assembly, Lift, 54"
7 683-0609 Bracket Assembly, LH-Front
8 683-0610 Bracket Assembly, RH-Front
9 683-0617 Stop Assembly, Chute
10 703-2093 Baffle, RR, Inner
11 703-2392 Bracket
12 703-3511 Guard, Finger
13 710-0528 Hex Screw, 5/16-18, 1.25, Gr5,
14 710-0602 Screw, Self-tapping, 5/16-18, 1.000
15 710-0604A Screw, Self-tapping, 5/16-18, 0.625
16 710-0751 Hex Screw, 1/4-20, .620, Gr5,
17 710-1644 Screw, Carriage, 3/8-16, Gr5, 5.00
18 710-3011 Hex Screw, 3/8-16, 2.25, Gr5,
19 710-3073 Hex Screw, 5/16-18, 2.25, Gr5,
20 710-3168 Bolt, Carriage, 3/8-16 x 1.0
21 710-3178 Short Neck Carriage Bolt 3/8-16 x .75
22 711-0332 Pin, Clevis, .50 Dia x .78
23 711-1737 Pin, Roller, .5" Dia x 10.06 .
24 711-1762 Pin, Hinge, Dia .375 x 14.06
25 712-0417A Nut, Hex Flange, 5/8-18
26 712-0431 Nut, Flange Lock, 3/8-16
27 712-3004A Nut, Flange Lock, 5/16-18, Gr5
28 712-3010 Nut, Hex, 5/16-18, Gr5
29 712-3019 Nut, Hex, 7/16-14, Gr2
30 712-3022 Nut, Hex Lock, 1/2-13
31 712-3027 Nut, 1/4-20, Hexflg, Lock
32 714-0145 Pin, Click, .092 x 1.64
33 714-0470 Pin, Cotter, 1/8 x 1.25
34 714-3004 Pin, Cotter, 3/32 x 1.25
35 715-0108 Pin, Sprg, 1/4 Dia x 1.00
36 715-0246 Pin, Spring, 3/16 x 1.25
37 717-1553A Adjustment, Deck, Gear
38 731-0335 Roller, Deck
39 731-3005 Front Roller
40 731-3131A Deflector, Chute
41 732-0306 Spring, Compression, .406 x .531 x 1.75
42 732-0459 Spring, Extension, .94 Dia x 6.74
43 732-0934 Spring, Extension, 1.15 Dia x 5.99
44 732-3070 Torsion Spring .44 I.d. x 2.10
45 734-3058B Deck Wheel, 5" Dia.
46 736-0105 Washer, Bell, .375 x .870 x .063
47 736-0119 Washer, Lock, 5/16, Regular Duty
48 736-0134 Flat Washer, .812 ID x 1.38 OD x .1
49 736-0171 Washer, Lock, 7/16 , Regular Duty
50 736-0208 Flat Washer, .51 ID x 1.5 OD x .07
51 736-0921 Washer, Lock, 1/2 , Regular Duty
52 736-3027 Flat Washer, .531 x 1.75 x .090
53 736-3039 Flat Washer .406 ID X 1.5 x 11ga
54 736-3072 Washer, Flat .38 ID x.93 OD x.110
55 738-0295 Shoulder Screw, .750 x .47.12
56 738-1229 Shoulder Screw, 5/8 Dia x 2.50 .
57 738-3056 Shoulder Screw, 1/2 Dia x 2.50 .
58 742-0677 Blade, 18.50"
59 747-1116 Deck Release Handle Rod, .375 Dia
60 750-0151 Spacer .550 ID x .755 OD x 1.1
61 750-0212 Spacer, .82 ID x 1.00 OD x .53
62 750-3213 Spacer, .405 x .75 x 3.875
63 754-0642 Belt, V-Type, B Section
64 756-3105 Pulley, Idler, 5.0 Dia.
65 783-1453 Bracket, Mounting, 54" Roller
66 783-1454 Bracket, Roller, Front
67 783-1455 Bracket, Idler
68 783-1470 Cover, Spindle RH
69 783-1471 Cover, Spindle LH
70 783-1479 Deck Shell Assembly, 54"
71 783-1482 RH Skirt
72 783-1483 LH Skirt
73 783-1484 LH Extension Skirt
74 753-04000 54-inch Deck Assembly Complete
REF.
NO.
PART
NO. DESCRIPTION
