10
OPERATION
Leaf Collection System Usage
NOTE: When leaf collection system is full, place the mower, cart and leaf collection system on a firm,
level surface, disengage the PTO, turn the mower engine (motor) off and set the parking brake.
1. Carefully release the dump mechanism on the cart, if one is present.
IMPORTANT: If using bed tilt feature to dump cart, remove hose from chute elbow prior to raising
cart bed to prevent damage to hose.
2. Open mesh cover by unzipping the two zippers upwards, and lifting the rear
flap of the mesh cover as shown in Figure 31.
3. Empty the leaves/grass clippings at a proper disposal site, using a rake to
pull the contents through the rear of the cart.
4. Close the rear flap by zipping the two zippers downwards, ensuring the
plastic flaps are tucked inside the cart, restart your towing device, release
parking brake and resume leaf/grass clipping collection.
Figure 31
