MTD YARD MACHINES 607 - Page 39

39
Model 607, 608 & 609
REF.
NO.
PART
NO. DESCRIPTION
1 716-0231 E-ring, .75
2 721-0338 Seal, .75 x 1.0 x .125
3 711-1431 Drive Shaft
4 741-0340 Sleeve Bearing, .75 x .1.0 x 1.0
5 736-0495 Thrust Washer, 1.0 x .632 x .0
6 717-1362 42-tooth Bevel Gear
7 717-1363 42-tooth Bevel Gear
8 750-1234 Spacer, .633 x 1.0 x .513
9 718-0228 Clutch Collar
10 741-0525 Needle Bearing, .625 x .875
11 719-0394 Lower Housing
12a 736-0336 Flat Washer, 5/8 x 1.0 x .030*
12b 736-0337 Flat Washer, 5/8 x 1.0 x .040*
12c 736-0349 Flat Washer, 5/8 x 1.0 x .020*
13 736-0519 Flat Washer, .70 x 1.125 x .031
14 741-0336 Flange Bearing, 5/8 x 3/4 x 3/4
15 741-0337 Flange Bearing, 5/8 x 3/4 x 15/16
16 750-1238 Spacer, .635 x 1.0 x .27
17 611-0133 Detent Shaft Assembly
18 618-0424 Differential Assembly
19 661-0006 Brake Assembly
20 710-1325 Self-tapping Screw, 1/4-20 x 1.625
21 710-1206 Self-tapping Screw, 1/4-20 x 2.375
22 717-0678 Brake Pad
23 732-0863 Compression Spring
24 741-0862 Detent Ball
25 761-0202 Brake Disc
26 711-1430 Input Shaft
27 716-0108 Retaining Ring, .437
28 717-1464 14-tooth Bevel Pinion
29 719-0391A Upper Housing
30 736-0723 Thrust Washer, .635 x 1.25 x .042
*Use applicable flat washer (12a, 12b or 12c) in this application allowing proper end-play as instructed in MTD’s Service Manual.
