SECTION 4: KNOW YOUR LAWN TRACTOR
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
A PTO (Power Take-off) Lever‡ G Throttle Control Lever
PTO (Power Take-off) Knob‡ H Cruise Control Button‡
B Choke Control‡ I Ignition Switch
C Parking Brake Button J Brake Pedal
D Shift Lever K Drive Pedal
E Cup Holder‡ L Deck Lift Lever
F Systems Indicator Monitor† M Seat Adjustment Lever‡
I
B
A
H
C
D
E
L
K
J
M
G
F
1
/
1
0
+
P
NOTE: Steering Wheel not shown for clarity.
A
† Style varies by model
‡ If so equipped
