MTP 7205 - Performance Index

Section Eight: Performance Index
Output Performance Index (applicable to temperature range from 18℃ to 28℃, within one year after calibration)
Output
Range
Output Range
Resolution
Accuracy
Remark
DCA
20mA
0.000～22.000mA
0.001mA
±0.05% set value
±4uA
Max. load 1KΩat 20mA.
Simu-
transmitter(absorption
current)
-20mA
0.000～-22.000mA
0.001mA
±0.05% set value
±4uA
Max. load 1KΩat 20mA.
Note: power supply range:
5～25VDC
Loop Power Supply
24V
10%
Max. output current up to
25mA.
Input Performance Index(applicable to temperature range from 18℃ to 28℃, within one year after calibration)
Input
Range
Output Range
Resolution
Accuracy
Remark
Voltage
28V
-0.200～28.000V
1mV
±0.02% reading±2mV
Input resistance about 1MΩ
Current
20mA
-1.000～22.000mA
0.001mA
±0.02% reading±4uA
resistance about 20Ω
Loop Current
20mA
0.000～22.000mA
0.001mA
±0.02% reading±4uA
providing 24V loop power
