MTS Exceed™ Series 40 Product Manual
66
Model E45.605 Accessory Mounting Dimensions
Installation
Top beam
100
2-Φ5.4x12
Φ82 Thru
Model E45.605 Underside of Crosshead Mounting Dimensions
700
2-M42x70
Φ32.5 Thru
vΦ65x60
Model E45.605 Topside of Top Beam Mounting Dimensions
2-Φ5.4x12
50
Φ32.5 Thru
Model E45.605 Underside of Top Beam Mounting Dimensions
0Exceed product manual.book Page 66 Wednesday, August 27, 2014 2:55 PM
