MTS Exceed™ Series 40 Site Preparation Guide
18
Packaging Dimensions and Weight
System Specifications
Packaging Dimensions and Weight
The following table provides the dimensions of various load frame types when
packaged for shipping. If you transfer the load frame from the shipping dock to
its final site location before unpacking the system, then use these dimensions to
ensure that the frame fits through all doorways and hallways.
Packaging Dimensions for Load Frames
M
ODEL
W
IDTH
D
EPTH
H
EIGHT
W
EIGHT
E42.503 920 mm
(36.22 in)
840 mm
(33.07 in)
1510 mm
(59.45 in)
290 kg
(638 lb)
E42.503E 920 mm
(36.22 in)
840 mm
(33.07 in)
1810 mm
(71.26 in)
330 kg
(726 lb)
E43.104 970 mm
(38.19 in)
945 mm
(37.20 in)
1835 mm
(72.24 in)
380 kg
(836 lb)
E43.104E 970 mm
(38.19 in)
945 mm
(37.20 in)
2135 mm
(84.06 in)
420 kg
(924 lb)
E44.104; E44.304 1120 mm
(44.09 in)
880 mm
(34.65 in)
2230 mm
(87.80 in)
650 kg
(1430 lb)
E44.104E; E44.304E 1120 mm
(44.09 in)
880 mm
(34.65 in)
2490 mm
(98.03 in
695 kg
(1529 lb)
E45.105 Single zone 1520 mm
(59.84 in)
1050 mm
(41.34 in)
2510 mm
(28.82 in)
1880 kg
(4136 lb)
E45.105 Double zone 1520 mm
(59.84 in)
1050 mm
(41.34 in)
2510 mm
(28.82 in)
1910 kg
(4211 lb)
E45.105E Single zone 2740 mm
(107.87 in)
1500 mm
(59.06 in)
1330 mm
(52.36 in)
1980 kg
(4356 lb)
E45.105E Double zone 2740 mm
(107.87 in)
1500 mm
(59.06 in)
1330 mm
(52.36 in)
2010 kg
(4431 lb)
E45.305 Single zone 1200 mm
(47.24 in)
1520 mm
(59.84 in)
2750 mm
(108.27 in)
2230 kg
(4916 lb)
E45.305 Double zone 1200 mm
(47.24 in)
1520 mm
(59.84 in)
2750 mm
(108.27 in)
2275 kg
(5016 lb)
E45.305E Single zone 3040 mm
(119.69 in)
1560 mm
(61.42 in)
1410 mm
(55.51 in)
2330 kg
(5137 lb)
E45.305E Double zone 3040 mm
(119.69 in)
1560 mm
(61.42 in)
1410 mm
(55.51 in)
2375 kg
(5236 lb)
E45.605 3160 mm
(124.41 in)
1960 mm
(77.17 in)
1760 mm
(69.29 in)
3602 kg
(7941 lb)
