MTU 8 V 2000 M84 - Page 76

10V2000
Position Cylinder 1 2 3 4 5 6 7 8 9
Firing TDC in cylinder A1 Bank A E A - - - - - A E -
Bank B E - - - - A E A E -
Overlap TDC in cylinder A1 Bank A - - E A E A E - - A
Bank B - A E A E - - - - A
“E” = inlet valve clearance adjustment permitted, “A” = exhaust valve clearance adjustment permitted
12V2000
Position Cylinder 1 2 3 4 5 6 7 8 9
Firing TDC in cylinder A1 Bank A E A E - - A E - - A - -
Bank B E - - - - A E - E
A
- A
Overlap TDC in cylinder A1 Bank A - - - A E - - A E - E A
Bank B - A E A E - - A - - E -
“E” = inlet valve clearance adjustment permitted, “A” = exhaust valve clearance adjustment permitted
16V2000
Position Cylinder 1 2 3 4 5 6 7 8 9
Firing TDC in cylinder A1 Bank A E A - A - A E - - A E - - - - -
Bank B E - - A - - E - E
A
E - E
A
- A
Overlap TDC in cylinder A1 Bank A - - E - E - - A E - - A E
A
E A
Bank B - A E - E A - A - - - A - - E -
“E” = inlet valve clearance adjustment permitted, “A” = exhaust valve clearance adjustment permitted
18V2000
Position Cylinder 1 2 3 4 5 6 7 8 9
Firing TDC in cylinder A1 Bank A E A E - - A E - - A - - - A - - - -
Bank B - A - A - - E A - - E
A
E - E A E -
Overlap TDC in cylinder A1 Bank A - - - A E - - A E - E A E - E A E A
Bank B E - E - E A - - E
A
- - - A - - - A
“E” = inlet valve clearance adjustment permitted, “A” = exhaust valve clearance adjustment permitted
4. Use feeler gauge to determine the distance between valve bridge and rocker arm.
5. If the deviation from the reference value exceeds 0.1 mm, adjust valve clearance.
