MTX RT501 - Introduction; Specifications; Control Panel

SPEAKER
+ -
GND REM +12V FUSE
POWER
LINE OUT LINE IN
HLI
+ R - G - L +
GAIN X-OVER LPF HPF
EBC Port
R
R
LL
6V 0,1V
40Hz 400Hz
FULL
HPF LPF
40Hz 400Hz
www.mtx.com - www.mtx.eu.com
Introduction
Thank you for purchasing an MTX Audio Hi-Performance amplier. Proper installation matched with MTX speak-
ers and subwoofers provide superior sound and performance for endless hours of waking the neighbors, slam-
min' your friends or at out stomping wanna-be players. Congrats and enjoy the ultimate audio experience with
MTX !
Specications
• 1-Channel Mono Block Wide Range Class-AB Power Amplier
• CEA2006 certied Power Output :
- 500 watts RMS x 1-channel at 2 ohm and THD+N ≤1%
- 300 watts RMS x 1-channel at 4 ohm and THD+N ≤1%
• Crossover :
- High pass 12dB/oct variable from 40Hz to 400Hz
- Low pass 12dB/oct variable from 40Hz to 400Hz
• Signal-to-Noise Ratio (1 watt) : > 80dB
• THD+Noise (Distortion) (1 watt) : ≤ 1%
• Frequency Response (±1dB) : 20Hz-30000Hz
• Maximum Input Signal : 6V
• Maximum Sensitivity : 100mV
• Dimensions : 414mm x 180mm x 55mm
• High level inputs
• EBC (External Bass Control) remote included
Control Panel
Owner’s Manual - RT501
