14
SPECIFICATION
Amplifier Type: Class A/B
Frequency response: 35 Hz - 160 Hz
Lo-pass xover 60 Hz - 160 Hz at 18 dB per octave
Inputs: Line level and speaker level full range
Outputs: Line level
Hi-pass subsonic filter: 18 dB per octave below 30 Hz
Polarity switch: Normal (0 degrees)/reverse (180 degrees)
Amplifier
Power: (continuous) 100 watts
Driver
Size: 12”
Voice coil diameter: 1-1/2”
Dimensions
Height: 17-1/2”
Width: 15”
Depth: 17” (17 7/8” Including Amplifier)
Weight
System: 35.5 lbs
Shipping: 39 lbs
Specifications subject to change without notice.
SAFETY SYMBOLS AND STATEMENTS
