MTZ 1220.1/1220.3 Section D . Operation controls and instruments
D15
Gearbox control (16F+8R)
The gearbox is controlled by two levers:
a lever of ranges shifting (1) and a lever
of gears shifting (2).
Select the required ranges and gears in
accordance with the shifting patterns I
and II as shown on the figure below.
IMPORTANT! In order to shift the gear correctly smoothly, without jerks, move the
gear shifting lever (2) in accordance with the pattern (see the figure above) and keep it
pressed until the gear is switched.
