FRAME GREASING:
Grease swivel assembly ttings annually or every 100
hours with a good quality marine grease available at any
auto parts store. Mercury marine grease is also
acceptable.
Locate and grease the three grease ttings on the
horizontal swivel located under the engine mount and the
single tting on the vertical swivel.
Owner Service:
DRIVE GREASING:
Grease annually or every 50 hours with a good quality
marine grease (NLGI 2.5) available at any auto parts store
or on the Excel Boats Online store.
Grease the throttle cable on both ends. Also, spray a wa-
ter resistant silicone spray on the throttle lever. To
prevent cable freezing, remove the cable and soak in WD-
40 for two hours each year.
Locate the drive lubrication zerk screw
located on the drive near the prop.
Remove the pressure release bleed
screw and grease the drive. Grease
until clean grease comes out of the
bleed screw hole. Replace the bleed
screw.
HDR TRANSMISSION SERVICE - EVERY 100 HOURS:
Disconnect the battery cable.
Carefully remove the clutch cover and disconnect the
plug. Locate the two ll/drain screws located on the belt
drive transmission.
Place a shop towel between the belt, below the
transmission to catch oil and any parts that might fall.
Cut a cup in half to catch the oil and drain and replace the
transmission uid with a good quality 10w-30 automotive
grade full synthetic oil.
15 16
