Technical specifications
Technical specifications of the joystick
12
3032258305-02-EN
Technical specifications
Technical specifications of the joystick
Parameters
Value
Operating voltage
10.5 V to 16 V DC
Temperature range
-20°C to +70°C
Current consumption
40 mA
Protection rating
IP20
Sub-D connector pin assignment
Pin no.
Signal
Pin no.
Signal
1
CAN_L_out
6
GND_E
2
CAN_L_in
7
CAN_H_in
3
CAN_GND
8
CAN_EN_out
4
CAN_H_out
9
+12 VE
5
CAN_EN_in
CPC connector pin assignment
Pin no.
Signal
Pin no.
Signal
Pin no.
Signal
1
12 VE
4
CAN_H
7
12 VE
2
CAN_L
5
CAN_H
8
3
CAN_L
6
9
0 VE
Disposal
When it has reached the end of its service life, please dispose of this
product as electronic scrap in accordance with all applicable waste
management laws.
