4) Connect the “DEVICE 1” jack of your SR to the “LINE
2”
side of the
2-
line
adapter with a
line
cord.
5) Connect your data devices and/or other telephones to the DEVICE 2
(or 3)
jacks
on
your SR. These devices or phones will be rung by your
additional telephone number(s).
6) For
each
wall jack
in
your home, disconnect anything plugged into it.
Insert a 2-line adapter and re-connect the cord to the
,“LINE
2”
side
of the
adapter. If it
is
impractical to insert a 2-line adapter (for example, with a
wall-mount
telephone), convert this
jack
by:
a. Swapping the GREEN wire with the BLACK wire
b. Swapping the RED wire with the YELLOW wire
Then plug the phone
back
into the converted
jack.
D. Partial Supervision with One SR
Ring
Supervision:
Fair
Barge-in
Protection:
Sorry!
Install,
Ease/Expense
Excellent
If left to your own devices (ha, ha; bad
pun),
this
is
the installation that you
would probably stumble
upon,
and then
call
your dealer and complain that
your SR doesn’t work the way you wanted.
‘SR
‘GtSeriess
15
