4. ELECTRONIC BATTERY CHARGER OPERATING MANUAL
TECHNICAL FEATURES OF THE Charger Multi-Mover M18.
There is 1 model : 24 Volt 5A
• 5A charger is supplied with the M18 with 2 x 12V 26AH batteries.
The innovative characteristics of the M18 range of 24 Volt battery chargers are:
1. Trickle-Charger System technology
2. Charging process fully controlled by microprocessor.
3. Universal input voltage 100-240 VAC
4. Charging process start in the "soft start" mode.
5. Protection against polarity inversions, short-circuits, over-voltages or anomalies by means of an
output relay.
6 Battery to battery charger connection without sparks on the output terminals with obvious
advantages for the active safety, thanks to the recognition of the battery voltage downstream
the normally open output relay.
7 Signaling of possible anomalies by red LED Flashing.
8. Insensitive charge parameters in case of 10% network voltage oscillations.
9. Efficiency > 85%.
10. Output ripple at maximum charge lower than 100mv.
12. Start of the charge cycle even with 2 x 8V is 16 Volt batteries.
OPERATING PRINCIPLE
Before proceeding to charge battery make sure you read all provided safety instructions.
1. Make sure that the charger is connected to AC power and Green LED is ON.
2. Connect the battery to the charger.
3. Orange LED indicates, "CHARGING".
4. Green LED indicates "FULL CHARGE".
VISUAL SIGNALS
Please find in the following table a list of the visual signals :
