1 ST2.9*10SCRE 18 O-ring 35 Lock catch
2 Rear cover 19 22 Needle spring 36 Microswitch
3 Cotton filter 20 Needle set 37 Battery pack
4 Right cover 21 Gun 38 Battery pack pin
5 Switch plunger spring 22 Pipette 39 Left cover
6 Switch plunger 23 Cup-ring 40 Gun-ring
7 Right side cover 24 Suction pipe splint 41 Stpper
8 ST3.5*10SCRE 25 Container 800ml 42 Motor cover
9 Big nut 26 Ꝋ3 flat gasket 43 550 motor
10 Spray ball 27 Short pin 44 Wind mill
11 Spray nozzle 28 Ajdusting knob 45 M4*8SCRE
12 Barge board 29 Trigger 46 Motor gasket
13 Nozzle seal 30 Spray a knob 47 Wind leaf
14 Needle 31 Left side cover 48 Wind cover
15 Needle insert 32 O-ring 49 Damping ring
16 Needle seat 33 Atomization circle 50 Funnel
17 Bowl seals 34 Vent spring 51 Pin
