The interior of the control box houses all of the electronics required to operate the labeler.
Labeling systems with a vacuum take-away will contain 2 servo-drive controllers while a system
with a powered rewind will contain 3 servo-drive controllers. See page 15 for conguration examples.
1 Primary Keypad - Allows operator to access and adjust the labeler’s main drive settings.
2 Powered Unwind Keypad - Allows operator to access and adjust the labeler’s powered unwind
settings.
3 Powered Rewind Keypad - Allows operator to access and adjust the labeler’s powered rewind
settings.
