Multifeeder MFT 102hsm - Label Product Sensor Advanced Calibration - Calculation

[
64
]
Label Product Sensor Advanced Calibration - Continued
6
8
=
Action Displayed
SYSTEM DIAGNOSTICS ITEM 2 OF 24
PRODUCT SENSOR
1-4 SELECTED(0):1=255,2=255,3=102,4=36
7
Value=(255–(Drive 3 Value))
x
(.25)+(Drive 3 Value)
Example:
9
=
MODE: ADVANCED TIPPING LABELER
STATUS : READY PRODUCT COUNT 1
PROGRAM NUMBER
