Multifeeder MFT 102hsm - Control Box External Connections

Main
Encoder
Unwind
Encoder
Rewind
Encoder
Main
Motor
Power Entry
Module
Unwind
Motor
Rewind
Motor
J24 - Motion Stop J22 - Signal Light
J23 - Line Speed Encoder
J6 - Product Sensor
J10 - RS485
J7 - Descrete I/O
J1 - Start Sensor
J3 - Low Product
J2 - APL Interface
J4 - RS232/Remote Keypad
J25 - RS232
J24 J22
J23
J10
J1 J2
J3
J4
J7
Lower Unwind Sensor
Upper Unwind Sensor
Lower Rewind Sensor
Upper Rewind Sensor
Vacuum Rewind
J25
J6
[
74
]
Control Box External Connections
