39
]
In normal operation, the label product sensor can be setup by positioning the last 5 mm of the trailing
edge of the label below the product sensor and then pressing the
SET PROD
THICKNESS
key. If however, the labeler
product sensor has been moved and becomes seriously out of adjustment, the following setup
instructions will restore the labeler product sensor to normal operation:
1 When required use an 1.5mm allen wrench to align the emitter and receiver as illustrated.
2 Position the labeler product sensor within the safe sensor area that is 5mm from any edge of the
label.
Continue on the next page.
