The Label Stop Position is where the label stops with respect to the Peel Edge after an application
cycle. However certain applications may require adjusting the Label Stop Position. Follow the
instructions below to adjust the Label Stop Position as required.
1 The Stop Position is the where the label stops after the completion of an application cycle.
2
From the READY screen on the controller, press the
MENU
key.
3
Press the key to select SETTINGS.
Continue on the next page.
Note - Follow the rules below to ensure proper label feeding when adjusting the Label Stop
Position.
• Never use a minimum product length longer than the length of the label.
• Never use a minimum product length that makes the label stop past the sensor. If this happens,
then instead move the sensor down-stream so the product stops under the sensor.
• This distance and location are dependent on:
• Length of label
• Speed of labeler
• Deceleration value for motor
• Desired stop position of the label on peel plate
