- Click Next and wait until the driver is installed
4.2 GUI
For GUI installation and operation, refer to the link below. GUI user manual is available for
detailed description (CMIS GUI Manual icon).
https://multilaneinc.com/products/ml4064-mcb/
5. Hardware Revision
- ML4064-MCB-RevA: Initial Version
- ML4064-MCB-RevB: Remove the drive buffer from H_LPWn signal circuit
6. Firmware Revision
- ML4064-MCB_V1_2: latest FW revision, compatible with the ML4064-MCB RevB
hardware.
7. Bootloader
Accessing in bootloader mode allows the user to reprogram the microcontroller, this is done as
described below:
1. Connect a jumper on (J1) situated close to the microcontroller.
2. Connect a USB cable between the PC and Board.
3. Power up the board with a +3.3V supply.
4. LEDs (D12, D13) start blinking.
5. Remove jumper.
6. Open the software “Microchip USB HID Bootloader v2.3”.
7. Click on “Open Hex File”.
8. Choose the new FW to download.
9. Click on “Program/Verify”.
10. Once the software finishes programming press on “Reset Device”.
11. After reset the Firmware is successfully updated.
