Multiplex 2803 - Page 12

Installation Section 2
2-2 Part Number 000003912 6/17
REMOTE CONDENSER
BLADE TOWER
OPTIONAL
38.00" (96.52 cm)
34.00" (86.36 cm)
30.00" (76.20 cm)
29.50"
(74.93 cm)
29.16"
(74.06 cm)
6.00"
(15.24 cm)
3.50"
(8.89 cm)
4.00"
(10.16 cm)
14.62"
(37.13 cm)
6.50"
(16.51 cm)
OPTIONAL
20.00" (50.80 cm)
16.00" (40.64 cm)
12.00" (30.48 cm)
1.50"
(3.81 cm)
27.94"
(70.97 cm)
.75"
(1.9 cm)
1.75"
(4.4 cm)
5"
(12.7 cm)
7.39"
(18.8 cm)
3" (7.6 cm)
3.29" (8.4 cm)
11.86" (30.1 cm)
9.68" (24.6 cm)
17.3"
(43.9 cm)
10.75"
(27.3 cm)
4.88"
(12.4 cm)
