17
Parts list
Part No. Description Purpose Material dimensions
No. off
1 1 Building instructions A4
2 1 Name placard decal set Printed film Ready made
3 1 Epoxy fuselage White GRP Ready made
4 1 Wing set (3-part) balsa Ready made
5 1 Tailplane and elevator Balsa Ready made
6 1 Fin and rudder Balsa Ready made
7 1 Vacuum-moulded canopy Plastic Ready made
8 1 Servo fairing Plastic Ready made
Wooden parts
10 1 Towhook block Fuselage Spruce 10 x 10 x 40 mm
11 1 Servo plate Fuselage Plywood 3 x 32 x 50 mm
12 2 Servo mounting block Fuselage Obechi 6 x 23 x 32 mm
13 1 Canopy plate Canopy Plywood 3 x 15 x 30 mm
14 3 Channeled rail Canopy / bowden cable Obechi Ready made, 40 mm
15 1 Dowel Tailplane / wing Beech 4 Ø x 100 mm
16 1 Support plate Tailplane Plywood 1.5 x 25 x 100 mm
17 1 Cross-piece Canopy Obechi 5 x 10 x 70 mm
Accessories
29 2 Wing joiner Wing Steel 6 Ø x 120 mm
30 1 Screw Wing Plastic M5 x 20 mm
31 1 Screw Wing Plastic M5 x 50 mm
32 1 Screw Tailplane Plastic M4 x 25 mm
33 1 Washer Wing Plastic Ready made, M5
34 1 Washer Wing Plastic Ready made, M4
35 1 Towhook Fuselage Steel Ready made
36 4/8* Metal clevis Linkage Steel M2
37 2 Threaded coupler Linkage Brass M2
38 2/4* Hexagon nut Linkage Brass M2
39 2 Horn, 3 holes Elevator / rudder Plastic Ready made
40 2/4* Horn spreader plate Linkage Plastic Ready made
41 4/8* Horn fixing screw Elevator/rudder/aileron Steel M2 x 12 mm
42 1 Locating pin Canopy Spring steel 3 Ø x 40 mm
43 2* Pre-formed pushrod Aileron linkage Steel 1 Ø x 85 mm
44 2* Horn, 2 holes Ailerons Plastic Ready made
Wire set, alpha junior
50 1 Elevator pushrod Linkage Spring steel 1.3 Ø x 1000 mm
51 1 Rudder pushrod Linkage Spring steel 0.8 Ø x 850 mm
52 1 Bowden cable inner tube Rudder linkage Plastic 2/1 Ø x 1000 mm
53 1 Steel rod retainer Canopy Spring steel 1.3 Ø x 250 mm
Wire set, alpha club
50 1 Elevator pushrod Linkage Spring steel 1.3 Ø x 1200 mm
51 1 Rudder pushrod
Linkage Spring steel 0.8 Ø x 1100 mm
52 1 Bowden cable inner tube Rudder linkage Plastic 2/1 Ø x 1000 mm
53 1 Steel rod retainer Canopy Spring steel 1.3 Ø x 250 mm
* alpha 27
Akkubox parts Alpha 21electric
61 1 Motor bulkhead Birch ply 3 x 32 x 200 mm
62 1 Battery support Plywood Ready made
63 1 Battery retainer Plywood 3 x 24 x 24 mm
64 1 Spacer block Obechi 10 x 24 x 32 mm
65 1 Retainer block Obechi 10 x 24 x 32 mm
66 1 Screw Steel 2.2 Ø x 13 mm
Akkubox parts Alpha 27 electric
61 1 Motor bulkhead Birch ply Ready made, 4 mm
62 1 Battery duct floor Plywood 3 x 55 x 225 mm
63 2 Battery duct side Plywood 3 x 25 x 222 mm
64 2 Battery duct rear panel / strap Plywood 3 x 25 x 55 mm
65 1 Retaining block Obechi 12 x 25 x 40 mm
