Part No. Description Material Dimensions
No. off
25 6 Swivel pushrod connector Metal Ready made, 6 mm Ø
26 6 Washer Metal M2
27 6 Nut Metal M2
28 7 Socket-head grubscrew Metal M3 x 3 mm
29 1 Allen key Metal 1.5 mm A/F
30 4 Aileron pushrod, one Z-bend Metal 1 Ø x 70 mm
31 1 Wing retainer screw Steel M3 x 12 mm
32 1 Self-locking nut, wing retainer screw Steel M3
33 2 Washer Metal M3
34 1 Tailplane joiner rod Spring steel 2.5 Ø x 120 mm
35 2 Trim ballast weight, electric version Steel ball, 9 g 13 mm Ø
36 4 Spar in-fill piece Hardwood dowel 7.8 Ø x 40 mm
Injection-moulded plastic parts
40 2 Wing root moulding Inj. moulded plastic Ready made
41 1 L.H. wing retainer Inj. moulded plastic Ready made
42 1 R.H. wing retainer Inj. moulded plastic Ready made
43 1 L.H. wing retainer tongue Inj. moulded plastic Ready made
44 1 R.H. wing retainer tongue Inj. moulded plastic Ready made
45 1 Wing joiner, fuselage Inj. moulded plastic Ready made
46 1 Motor bulkhead Inj. moulded plastic Ready made
47 1 All-moving tailplane bellcrank Inj. moulded plastic Ready made
48 1 L.H. tailplane bellcrank bush Inj. moulded plastic Ready made
49 1 R.H. tailplane bellcrank bush Inj. moulded plastic Ready made
50 1 L.H. tailplane joiner moulding Inj. moulded plastic Ready made
51 1 R.H. tailplane joiner moulding Inj. moulded plastic Ready made
52 1 Tailplane retainer tongue Inj. moulded plastic Ready made
Flat plastic and vacuum-moulded parts
55 2 Fuselage spine Plastic Ready made
56 2 L.H. servo well fairing Vac. moulded plastic Ready made
57 2 R.H. servo well fairing Vac. moulded plastic Ready made
58 4 Tailplane spar GRP rod 1.3 Ø x 220 mm
Wire and rod
60 4 Inboard wing spar CFRP tube 10 Ø x 8 Ø x 900 mm
61 4 Outboard wing spar GRP tube 8 Ø x 5 Ø x 300 mm
62 1 Elevator pushrod, one Z-bend Metal 0.8 Ø x 840 mm
63 1 Rudder pushrod, one Z-bend Metal 0.8 Ø x 900 mm
64 1 Elevator snake outer sleeve Plastic 3 / 2 Ø x 740 (785*) mm
65 1 Rudder snake outer sleeve Plastic 3 / 2 Ø x 785 mm
66 1 Elevator snake inner sleeve Plastic 2 / 1 Ø x 790 (850*) mm
67 1 Rudder snake inner sleeve Plastic 2 / 1 Ø x 850 mm
68 1 R.H. snake outer sleeve, fuselage Plastic 3 / 2 Ø x 605 (785*) mm
69 1 Bottom fuselage longeron GRP rod 2 Ø x 755 mm
70 1 Top fuselage longeron GRP rod 2 Ø x 555 (755”) mm
* Length as supplied Æ cut to required length
