Scope of delivery / List of parts
Small parts
The versions contain the following additional accessories:
Serial no.
Qty. Name Material Dimensions
20 3 Hook and loop tape hook side Plastic 25 x 60 mm
21 3 Velour hook and loop tape Plastic 25 x 60 mm
22 2 Locking clip Injected plastic Finished component
23 2 Closure plug Injected plastic Finished component
24 2 Glue-in rudder horn Injected plastic Finished component
25 2 Pushrod connector Metal Finished component Ø6 mm
26 2 Washer Metal
27 2 Nut Metal M2
28 2 Hexagon socket set screw Metal M3 x 3 mm
29 1 Hex key Metal WAF 1.5
30 2 Aileron rods with Z. Metal Ø1 x 80 mm
31 1 Left servo hood Deep-drawn plastic Finished component
32 1 Right servo hood Deep-drawn plastic Finished component
33 1 Bulkhead Anodized aluminum Finished component
34 2 Screw for bulkhead Metal PT3.0 x 16 mm
36 1 Screw for bulkhead adjust. Metal M3 x 20 mm
37 1 Battery mount plate Plastic 20 x 60 mm
38 1 Fastening strap for battery Plastic 20 x 200 mm
39 1 Cable protection Plastic Finished component
Serial no.
Qty. Name Material Dimensions
1 1 Assembly instructions KIT
2A 1 Decal sheet (sheet A) Printed adhesive lm 350 x 500 mm
2B 1 Decal sheet (sheet B) Printed adhesive lm 350 x 500 mm
2C 1 Decal sheet (sheet C) Printed adhesive lm 350 x 500 mm
2D 1 Decal sheet (sheet D) Printed adhesive lm 660 x 120 mm
3 1 Fuselage Elapor Foamed finished component Silver
4 1 Fuselage cover Foamed Elapor
Finished component silver
5 1 Canopy Foamed Elapor
Finished component silver
6 1 Left wing Foamed Elapor
Finished component silver
7 1 Right wing Foamed Elapor
Finished component silver
8 1 Vertical tail left Foamed Elapor
Finished component silver
9 1 Vertical tail right Foamed Elapor
Finished component silver
10 1 Spar tube CFRP tube Ø6 x 4 x 575 mm
11 1 Bulkhead holder FunJet Injected plastic Finished component
12 1 Canopy glass Deep-drawn plastic Finished component
Qty. Name FunJet 2 KIT
+
#1-01029 FunJet ULTRA 2 KIT
+
#1-01030
1 Power kit # 1-00961 # 1-00962
2 Servos HS-65 HB # 11 2065 # 11 2065
2 Extension cable 15cm # 8 5019 # 8 5019
1 Plug fuses # 1-00137 # 1-00137
