Part List RR/RR+/RTF FunMan
Part No. Description Material Dimensions
No. off
1 1 Building Instruction Paper A4
3 1 Fuselage and cabin, factory-assembled,
two servos, motor and controller installed Elapor foam Ready made
6 1 Wing, factory assembled Elapor foam Ready made
7 1 Tailplane with horn and pushrod Elapor foam Ready made
8 1 Fin with horn and and pushrod Elapor foam Ready made
Small parts set
20 2 Hook-and loop-tape, hook Plastic 25 x 60 mm
21 2 Hook-and loop-tape, loop Plastic 25 x 60 mm
29 1 Allen key Metal 1,5 A/F
32 1 Screw Plastic M5 x 50mm
35 1 Snake outer sleeve Plastic 3 x 2 x 90 mm
47 1 Steel rod Metal 1,3 x 250 mm
75 1 Screw Metal M3 x 12mm
Undercarriage
70 1 Main undercarriage with two
Ø 75mm wheels Metal / Plastic Ready made
Airscrew
52 1 MPX-Airscrwe 8x5“ Plastic Ready made
53 1 Propeller drive Metal Ready made
Additional RC-components (only at RR+/RTF)
1 Receiver RX-5 Smart ID7
1 Battery LiBatt FX 3S 950 mAh
Additional RC-components at RTF
1 Transmitter SMART SX
1 Manual SMART SX
3 Batteries Mignon (AA)
1 Charger MULTIcharger L-703 EQU
A
