10
Accessories and tools
Wingspan 930 mm
Overall length 810 mm
All-up weight 180 g
Control channels 4 (5)
RC functions Elevator, rudder, aileron, throttle
(optional landing aps)
Flight time 6 min.
Specication
Essential accessories
• 1 x Zacki-ELAPOR
®
# 85 2727 # 85 2727
• 1 x Zacki-ELAPOR
®
super liquid # 85 2728 # 85 2728
• 1 x Zacki Activator #1-01032 # 1-01032
• UHU
®
POR
• Small cross-point screwdriver
• Balsa knife
• Pointed-nose pliers
• 1 sheet abrasive paper, 320-grit
• 1 mm drill
• 1.5 mm drill
KIT contents
• Colour-printed EPP components for fuselage, wings, tailplane, n
and undercarriage
• CFRP spars for wings and fuselage
• CFRP undercarriage unit
• Wheels
• All plastic parts, small items and linkage components required to
complete the model
• 1x Extra 330 SC Indoor / FunnyCub power set V2 # 1-01026
• 4x HS-40 servo # 11 2040
• 1x RX-5 light M-LINK 2.4 GHz receiver # 5 5808
• 1x ROXXY EVO LiPo 2 - 450B 30C with BID chip # 1-00016
Essential tools and materials
Parts List
Part No. Quant. Description Material Dimensions
1 1 FunnyCub building instructions Paper DIN A4
2 1 Model complaint notication Paper DIN A5
3 1 Upper fuselage section EPP Ready made
4 1 Lower fuselage section EPP Ready made
5 1 Fuselage centre section EPP Ready made
6 1 Left wing EPP Ready made
7 1 Right wing EPP Ready made
8 1 Left tailplane EPP Ready made
9 1 Right tailplane EPP Ready made
10 1 Fin EPP Ready made
11 4 Outer wheel section EPP Ready made
12 2 Inner wheel section EPP Ready made
13 10 Round-section rod CFRP 1.0 Ø x 400 mm
14 3 Round-section rod CFRP 0.8 Ø x 500 mm
15 2 Round-section rod CFRP 1.5 Ø x 228 mm
16 2 Round-section rod CFRP 1.5 Ø x 215 mm
17 2 Round-section rod CFRP 1.0 Ø x 140 mm
18 4 Round-section rod CFRP 1.0 Ø x 100 mm
19 4 Round-section rod CFRP 1.0 Ø x 250 mm
20 2 Round-section rod (for linkages) CFRP 1.5 Ø x 60 mm
