Operating Instructions MULTIcont BL-30 2in1
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de Seite 5/10
Instructions MULTIcont BL-30 2in1, # 82 5914 (15-11-09/JES) • Errors and omissions excepted! •
MULTIPLEX
Connect the three-core receiver lead (attached to the speed
controller) to the receiver input socket used for motor
speed control:
- With MULTIPLEX RC systems: channel 4 = throttle / motor
- With HiTEC RC systems: channel 3 = throttle / motor
Pin assignment
Negative pin ()
brown
Positive pin (+) red
Signal ( ) orange
Do not connect a separate receiver battery to the receiver, as
the controller supplies current to the receiver and servos via the
BEC circuit. Disable the BEC system if necessary ( 7.).
5. USING THE UNIT FOR THE FIRST TIME
By default, this speed controllers are set up for use with LiPo.
1. Using the MULTIcont BL-30 2in1 controller for the
first time
1.1 Programmable RC
system
set servo travel for
throttle / motor to
100% in both
directions
1.2 Move transmitter
throttle stick (and trim,
if present) to the motor
OFF position
1.3 Transmitter ON
1.4 Connect a fully-
charged flight battery
Rising sequence of tones
In LiPo mode the number of
beeps indicates the detection
of a LiPo battery with X cells
(in NiXX mode the following
signals are emitted immediately)
Two rising tone sequences
Controller is ready for use
Q Note:
Programmable parameters
If you wish to change one of the programmable parameters,
please refer to the Programming section ( 6.).
Start-up protection
MULTIcont BL-30 2in1 speed controllers are only armed when
the throttle stick is moved to the motor OFF position, and when
the audible “ready” indication has been emitted.
Always carry out a range check
Every time you wish to fly, carry out a range check with the RC
system switched on. Check in particular that radio range is not
diminished at full-throttle and half-throttle, and that no
interference occurs. Watch the servos in the model: if they jitter
or carry out random movements, this indicates an interference
problem which must be solved.
6. PROGRAMMING
Programming the MULTIcont BL-30 2in1 speed controller could
hardly be simpler; it is carried out using the transmitter throttle
stick or - for even greater convenience - the MULTIPLEX
MULTImate # 8 2094.
Beeps indicate the status of programming when using the
transmitter stick, and also confirm any changes. The procedure
runs through all variable parameters step by step. You select the
desired programming option by moving the throttle stick either to
the full-throttle or motor OFF position. Returning the stick to
centre takes you on to the next programmable parameter.
0.
Activate programming mode
0.1
Flight battery disconnected
Stick to full-throttle position
Transmitter ON
0.2
Connect fully-charged flight
battery
Rising tone sequence
In LiPo mode:
Indicates detected LiPo
cell count
in NiXX mode the
following signal is emitted
immediately
Rising tone sequence
0.3
Stick to centre position
Rising tone sequence
0.4
Stick to full-throttle position
Rising tone sequence
0.5
Stick to centre position
Rising tone sequence
sounds four times: the
controller is now in
programming mode
1.
Select battery mode
(single beep, continuously repeated)
1.1
Automatic low-voltage cut-
off for LiPo batteries*
stick to full-throttle
position
OR:
For NiXX batteries
stick to motor OFF
position
Long tone
(confirmation signal)
1.2
Stick to centre position
2.
Select brake mode
(double beep, continuously repeated)
2.1
For brake ON*
stick to full-throttle
position
OR:
For brake OFF
stick to motor OFF
position
Confirmation signal
emitted
2.2
Stick to centre position
3.
Select direction of rotation
(triple beep, continuously repeated)
3.1
For reverse rotation
stick to full-throttle
position
OR:
For standard rotation*
stick to motor OFF
position
Confirmation signal
emitted
3.2
Stick to centre position
4.
Select motor cut-off type
(quadruple beep, continuously repeated)
4.1
For motor cut
(hard stop)
stick to full-
throttle position
OR:
For power
reduction *
stick to motor
Confirmation signal emitted
LiPo batteries:
Motor off at 3.0 V / cell
NiXX batteries:
Motor off at 6.0 V!
LiPo batteries:
Motor speed is reduced at 3.2 V /
