MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 103
LS400/LS500 PUMP — HOPPER ASSY.
HOPPER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EM515980 HOPPER ASSY 1
2 EM16184 HOPPER SEAL 1
3 EM516779 REMIXER SHAFT 1
4 EM200303 FOLLOWER RING 2
5 EM200301 GRAPHITE SEAL 6
6 EM516820 COMPRESSION SPRING 2
7 EM514339 HOPPER SPRING SEAT 2
8 510717 BOLT 1/2 X 1-3/4 IN. 4
9 EM514338 SUPPORT, LEFT 1
10 EM514706 END CAP, SHAFT SUPPORT 1
11 EM902153 BEARING 2
12 EM200018 SET COLLAR 1
13 EM703 SET SCREW ............................................ 2 ................ REPLACES 492470
14 500264 KEY 3/8 IN. 1
16 EM511428 BOLT 1/2 X 3-1/2 IN. 4
17 EM516780 HOUSING 1
18 EM98108 MOTOR, REMIX 1
19 505989 BOLT 1/2 X 1-1/4 IN. 2
20 6109180 WASHER, LOCK 1/2 IN. ........................... 2 ................ REPLACES 492626
21 EM25508 ADAPTER, FITTING 2
22 EM70860-1 PISTON CUP HOLDER 1
23 EM50417 PISTON CUP 1
24 EM508830 HANDLE 1
25 492378 BOLT 3/8 X 1-3/4 IN. 4
26 0166 A WASHER, LOCK 3/8 IN. ........................... 4 ................ REPLACES 492624
29 EM514031 PADDLE ARM, END 2
30 EM514032 PADDLE ARM, MOTOR END 2
31 EM514033 PADDLE ARM, CENTER 2
32 513454 BOLT 1/2 X 3-1/4 IN. 6
33 6109180 WASHER, LOCK 1/2 IN. ........................... 6 ................ REPLACES 492626
34 492589 HEX NUT 1/2 IN. ...................................... 6 ................ REPLACES 507661
35 EM25483 HOSE 2
36 EM70860 HANDLE ASSY. 1
37 EM515460 RETAINING RING 1
39 516799 SPACER 6MM 1
40 EM702 DOG POINT SET SCREW 3/8" 1
41 EM703 SET SCREW 3/8" 3
42% 516787 REMIX SHAFT COUPLER 1
43 EM500264 SQUARE KEY 3/8" 1
44% 516776 DRIVE MEMBER COUPLER 1
45% 516775 MOTOR SHAFT COUPLER 1
46 EM516786 COUPLER ASSY ...................................... 1 ................ INCLUDES ITEMS W/%
