MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 129
LS400/LS500 PUMP — ENGINE ASSY.
ENGINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EM98189 ENGINE, DEUTZ TURBO 76 HP BF4L2011 1
2 492401 BOLT1/2 IN.X 4 FT. 4
3 6109170
WASHER, FLAT 1/2 IN. ...........................................4............REPLACES 492600
4 6109180
WASHER, LOCK 1/2 IN. ......................................... 4............REPLACES 492626
5 EM511021 AIR DUCTING CLAMP 2
6
EM510725 AIR DUCTING CLAMP 2
7 EM511019 AIR DUCTING DUCTING 1
8 TBD CLAMP 3
9 EM510888 CONNECTOR, AIR FILTER 1
10 22001301 HOSE, ELBOW 90° 1
11 22002183 AIR CLEANER ASSY. .............................................1............INCLUDES ITEMS W/
*
12
*
01881280 HOOD, AIR CLEANER 1
13
*
01319257 INSERT, AIR FILTER 1
14
*
01880870 CARTRIDGE, SAFETY AIR 1
15
*
01881413 DUST EJECTOR 1
16
*
EM492366 BOLT 5/16 X 1-1/2 IN. 2
17
*
EM492623 WASHER, LOCK 5/16 IN. 2
18
*
EM492597 WASHER, FLAT 5/16 IN. 4
19
*
EM492553 NUT, HEX 5/16 IN. G5 2
24 EM514633 REDUCTION TUBE, EXHAUST 1
25 492371 BOLT 5/16 NC X 3 IN. G5 2
26 EM923023 WASHER, FLAT 5/16 IN. .........................................4............REPLACES 492597
27 EM514714 SPACER, EXHAUST 2
28 EM923343 WASHER, LOCK 5/16 IN......................................... 2............REPLACES 492623
29 2105164 HEX NUT 5/16 IN. G5.............................................. 2............REPLACES 492553
30 EM510897 CAP, EXHAUST 2-1/2 IN. 1
31 01174416 FILTER, OIL (ENGINE) 1
32 01174696 FILTER, FUEL (ENGINE) 1
33 EM516434 PIPE EXHAUST ASSY. 1
