MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 107
LS400/LS500 PUMP — HOPPER INTERIOR ASSY.
HOPPER INTERIOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EM16145A SWING AXLE BUSHING 2
2 EM284 STUD 1 IN. - 14 UNF 1
3 EM16175 O-RING 1
4 EM16170 RING SEAL, SHUTTLE AXLE 1
5 EM16176 O-RING 1
6 EM98022 WEAR RING HF 1
6A EM16816-1A RING, ENERGIZER RUBBER 1
7 EM16816-2 RING, INSERT STEEL 1
8 EM16804 SLEEVE 5 IN. ............................................ 1 ............... JUNE 2008 AND BELOW
8 EM16804A SLEEVE 5 IN. ............................................ 1 ............... JULY 2008 AND ABOVE
9 EM104 BOLT 5/8 X 2 IN. ........................................ 4 ............... REPLACES 503982
10 EM923348 WASHER, LOCK 5/8 IN. 4
11 EM25803 DISCHARGE PLATE BEARING 1
12 EM98065 SEAL, RUBBER 1
13 EM512212 DISCHARGE NIPPLE 1
14 491701 GREASE FITTING 3
15 EM210 BOLT 5/8 X 2 IN. 6
17 EM16811 SHUTTLE CYLINDER 1
18 EM25843 NUN PLATE 1
19 EM104 BOLT, HEX HEAD 5/8 X 2 IN..................... 4 ............... REPLACES 503982
20 491719 PIN 1
21 EM923348 WASHER, LOCK 5/8 IN. 4
25 EM514357 HOPPER SCREEN 1
26 EM98021 PLATE, WEAR HF 1
2
7 EM969023 NUT, HEX 5/8 IN. NC INS. ......................... 2 ............... REPLACES 492586
28 EM265 BOLT, COUNTER SUNK 5/8-11 x 3 IN. 2
29 EM923350 WASHER, LOCK 3/4 IN. ............................ 2 ............... REPLACES EM492628
30 EM151 BOLT, HEX HEAD 3/4-10 X 2 IN. 2
31 EM264 BOLT, COUNTER SUNK 1/2-13 x 3 IN. 2
32 EM517700 O-RING 2
