MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 109
LS400/LS500 PUMP — SHUTTLE CYLINDER ASSY.
SHUTTLE CYLINDER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EM16145 SWING AXLE BUSHING 2
2 EM510684 GREASE FITTING 1
3 EM16169 THRUST WASHER 1
4 EM25236 SHUTTLE CRANK, SPLINED SHAFT 1
5 EM505490 GREASE FITTING 2
6 EM16814 TENSIONER 1
7 EM424 HEX NUT 1 IN. 14NF 1
7A EM924006 COTTER PIN 5/32 X 2 IN. 1
8 EM417 NUT 1 IN. 14NF 1
9 EM98106 SHUTTLE CYLINDER ASSY. ....................... 1 ............ INCLUDES ITEMS W/
*
9A EM98106SK SEAL KIT, SHUTTLE CYLINDER 1
10
*
EM254549 BRACKET, PIVOT 1
11 492397 BOLT 1/2 X 2-1/2 IN. 4
12 EM621 WASHER 1/2 IN. 4
13 6109180 WASHER, LOCK 1/2 IN. ............................... 4 ............ REPLACES 492626
14 492584 NUT 1/2 IN. 4
15
*
0820270000 CLEVIS PIN 3/4 IN. 2
16
*
0820270000 COTTER PIN 2
18
*
515249 JAM NUT 1
19
*
0509440000 FEMALE CLEVIS 2
20 3322 FITTING, ELBOW 2
21 EM514590 HOSE 1
22 EM514591 HOSE 1
23 517742 COVER, SHUTTLE CYLINDER 1
24 0202 BOLT ............................................................. 3 ............ REPLACES 492364
25 EM923023 WASHER, FLAT ............................................ 3 ............ REPLACES 492597
26 2105164 NUT, HEX ...................................................... 3 ............ REPLACES 492582
