MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 111
LS400/LS500 PUMP — LUBRICATION PISTONS ASSY.
LUBRICATION PISTONS ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EM510265 BOLT, HEX HEAD 3/8 NC X 3-1/2 IN., BLACK OXIDE G8 6
2 EM16464 FACE PLATE 2
3 EM16465 PISTON CUP SPACER 6
4 EM98050 CUP, PISTON- ORANGE 2
5 EM14408 RING, BRONZE 2
6 EM16493 RING, FELT 2
7 EM16462 FELT HOLDER 2
8 EM16461 OILER PLATE 2
9 EM14407 O- RING, OILER PLATE 2
10 EM25801 CYLINDER, CONCRETE 2
11 EM25110 RETAINER, CYLINDER 4
12 EM963610 BOLT, 3/8 NC X 1.3/4 IN. G5...................................................8........ REPLACES 492375
13 0166 A WASHER LOCK 3/8 IN. ..........................................................8........ REPLACES 492624
14 3019092 WASHER, FLAT 3/8 IN. .........................................................22....... REPLACES 492598
16 EM514197 LUBRICATION BOX 1
17 EM507895 PLUG 1
18 EM515796 COVER, LUBRICATION BOX 1
19 EM514610 LATCH, COVER 1
20 491754 RIVET, AM-66 2
21 492378 BOLT, 3/8 NC X 1.3/4 IN. G5 6
22 0166 A WASHER, LOCK 3/8”..............................................................6........ REPLACES 492624
23 EM274351 SEAL LUBE BOX 2
24 EM50425 FLANGE, RING 2
25 492451 BOLT 3/8 - 24 X 1 IN. HEX HEAD 8
26 EM50443 SEAL, OIL BOX 8
27 514208 BAR,PROXIMITY SWITCH SUPPORT 1
28 EM98163 SWITCH, PROXIMITY W/CABLE 2
29 EM98135 CABLE HOUSING, FEMALE 2
30 EM98134 SEAL, CONNECTOR HOUSING 6
31 EM98138 TERMINAL PIN, FEMALE 6
32 514611 GROMMMET 2
33 504505 WRAP TIE 8
