MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 133
LS400/LS500 PUMP — WATER SEPARATOR ASSY.
WATER SEPARATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 514340 BRACKET, W
ATER SEPARATOR 1
2 TBD BOLT 2
3 EM16747 WATER SEPARATOR ASSEMBLY 1
3A P53712 CARTRIDGE, WATER SEPARATOR 1
4 492364 BOLT 5/16 X 1 IN. 3
5 2105164 HEX NUT 5/16 IN. ............................................. 3 ..............REPLACES 492582
6 EM514559 ELBOW ADAPTER 90° MALE 2
7 EM506208 CLAMP, HOSE 2
8 EM514536 HOSE 5/16 IN. TBD
