MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 135
LS400/LS500 PUMP — HYD. PUMP ASSY.
HYDRAULIC PUMP ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1
*
TBD O-RING 1
2 EM514719 FLANGE, SUCTION PIPE .......................................... 2 ............INCLUDES ITEMS W/
*
3 EM492444 BOLT 1/2 X 1-1/4 IN. 4
4 6109180 WASHER, LOCK 1/2 IN. .............................................. 6 ............REPLACES 492626
5 EM514718 SUCTION PIPE ADAPTER, 40 SPECIAL 1
6 EM515207 CLAMP 2 IN. ................................................................ 2
7 EM514623 HOSE, SUCTION 2 IN. 1
8 EM514627 ADAPTER, SUCTION PIPE 32 1
9 EM514628 FLANGE, SUCTION PIPE .......................................... 1 ............INCLUDES ITEMS W/%
10 EM510902 BOLT 1/2 X 1-1/2 IN. 4
11 6109180 WASHER, LOCK 1/2 IN. .............................................. 4 ............REPLACES 492626
12% O-RING 1
13 EM98128 COUPLER, ENGINE ASSY. 1
14 EM510902 BOLT 1/2 X 1-1/2 IN. 2
16 EM517674 PUMP, MAIN 60CC, PARKER P1-60 SERIES ............ 1 ............USED ON LS400 ONLY
16 EM98256 PUMP, MAIN 75CC, PARKER P1-75 SERIES ............ 1 ............USED ON LS500 ONLY
17 EM98273 FLOW CONTROL VALVE 1
18 EM506953 BOLT 7/16 X 3 IN. 4
19 EM16190 GASKET 1
20 EM98107 PUMP, SECONDARY 1
21 EM963610 BOLT 3/8 X 1 IN........................................................... 2 ............ REPLACES 492375
22 0166 A WASHER, LOCK 3/8 IN. .............................................. 2 ............ REPLACES 492624
23 EM25498 STRAIGHT ADAPTER 1
24 EM25429 ELBOW ADAPTER 1
25 EM514599 HOSE, 4000 PSI SENSOR ......................................... 1 ............USED ON LS400 ONLY
25 EM516875 HOSE, 4000 PSI SENSOR ......................................... 1 ............USED ON LS500 ONLY
26 EM25429 ELBOW ADAPTER 1
27 EM491372 STRAIGHT ADAPTER 1
29 EM25498 STRAIGHT ADAPTER 1
30 EM16524 ELBOW ADAPTER 90° MALE 2
31 506200 ELBOW ADAPTER 1
32 EM514601 HOSE 2000 PSI, REMIX VALVE 1
33 EM517649 MOTORIZED FLOW CONTROL MANIFOLD ASSY. 1
34 EM517038 HOSE, MAIN MANIFOLD 1
35 EM509353 ELBOW 1
36$ TBD VALVE, MAIN RELIEF 1
37 EM514608 HOSE 1
39 EM25459 ELBOW 1
40 EM25429 ELBOW ADAPTER 1
