MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 137
LS400/LS500 PUMP — MANIFOLD ASSY.
MANIFOLD ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 EM963102 BOLT 1/2 X 1-1/4 IN. ................................................ 4 .......... REPLACES 492393
2 6109180 WASHER, LOCK 1/2 IN............................................ 4 .......... REPLACES 492626
3 EM98261 MANIFOLD ASSY COMPLETE ...............................
1 .......... REPLACES EM98109
............................................................................................... INCLUDES ITEMS W/ %
4% EM98220 CYCLING VALVE, SWING W/PILOTS ...................... 1 .......... INCLUDES ITEMS W/ #
5# EMBK227 BOLT, SHCS 1/2" x 2-1/4" 12
6# EM98223 PILOT VALVE, SHUTTLE 1
7# EMBK2097 BOLT, SHCS 1/2" X 1-1/4" 8
8 EM98221 CYCLING VALVE, MAIN........................................... 1 .......... INCLUDES ITEM W/ &
9& EM98222 PILOT VALVE, MAIN CYLINDER 1
10% EM98227 CHECK VALVE 1
12% EM98228 COIL, 12VDC ACCUMULATOR 1
12A% EM98229 ACCUMULATOR UNLOADER CARTRIDGE ASSY 1
13 EM25498 ADAPTER 1
14 EM509401 ADAPTER 3
15 EM514488 ADAPTER 1
16 EM25459 ADAPTER 2
17 EM98226 UNLOADING RELIEF VALVE, SHUTTLE 1
18 EM514231 ADAPTER 2
19 EM514489 ADAPTER 2
20 EM491372 ADAPTER 1
21 506193 ADAPTER 1
22 EM25462 ADAPTER 2
23 EM509353 ADAPTER 3
24 EM25429 ADAPTER 1
25 TBD CHECK VALVE 1
