MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 139
LS400/LS500 PUMP — CONTROL BOX ASSY.
CONTROL BOX ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 CONTROL BOX ASSY ..................................... 1 ................ CONTACT FACTORY
2 0202 BOLT 5/16 X 1 IN. ............................................ 4 ................ REPLACES 492364
3 EM923023 WASHER, FLAT 5/16 IN. .................................. 4 ................ REPLACES 492597
4 2105164 NUT 5/16 IN. .................................................... 4 ................ REPLACES 492582
5 TBD OVERLAY, CONTROL PANEL 1
6 EM98206 IGNITION SWITCH ASSY. 1
7 EM98206K KEY, IGNITION 1
8 EM517177 EMERGENCY STOP SWITCH ASSY. 1
8A EM517186 CONTACT BLOCKS, EMERGENCY SWITCH 3
12 EM98120 FLOW DIRECTION SWITCH ASSY. 1
13 EM98119 MAIN CONTROL SWITCH ASSY. 1
14 EM98121 AUTO/JOG SWITCH ASSY. 1
15 EM98122 JOG A/B SWITCH ASSY. 1
18 EM97068 RECEPTACLE, REMOTE 1
19 TBD VOLUME SWITCH ASSY. 1
20 TBD SCROLL SWITCH ASSY. 1
21 TBD RESET SWITCH ASSY. 1
