MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 91
LS400/LS500 PUMP — FRAME ASSY.
FRAME ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 514355 FRAME, MAIN 1
2 EM516581 CHAIN, TRAILER HITCH, 3/8 X 40", GRADE 40 2
3 EM25610 JACK STAND, FRONT 1
5 EM744 CLEVIS PIN 2
8 EM491686 PIN 2
10 EM491744 RIVET, POP AM-44 2
11 509562 BOLT, 3/8" NC X 5/8" G5 2
12 0166 A LOCK, WASHER 3/8" ................................................2......... REPLACES 492624
13 503112 BOLT 3/8" X 2-3/4" 1
14 3019092 WASHER 3/8" ........................................................... 2......... REPLACES 492598
15 EM969013 NUT 3/8" ................................................................... 1......... REPLACES 492583
16 517985 FENDOR, BOLT ON 2
17 504456 BOLT 1/2" NC X 3/4" G5 12
18 6109180 WASHER, LOCK 1/2 IN. ...........................................12 ....... REPLACES 492626
19 517113 STABILIZER STAND 2
20 492376 BOLT 3/8" NC X 1-1/4" G5 2
21 0166 A WASHER, LOCK 3/8" ................................................4........ REPLACES 492624
23 EM969013 NUT 3/8" ....................................................................2 ........ REPLACES 492583
24 517124 BOLT 3/4" NC X 1" G5 10
25 EM923350 WASHER, LOCK 3/4 IN. ...........................................10 ....... REPLACES EM492628
26 517092 SUPPORT PLATE, RIGHT 1
27 517095 SUPPORT PLATE, LEFT 1
