MAYCO LS400/LS500 PUMP — OPERATION AND PARTS MANUAL — REV. #6 (09/19/11) — PAGE 93
LS400/LS500 PUMP — AXLE ASSY. (RIGHT/LEFT)
AXLE ASSY. (RIGHT/LEFT)
NO. PART NO. PART NAME QTY. REMARKS
1 EM98116 AXLE, T
ORSION BAR ASSY. 2
2 EM092305 BRAKE ASSY COMPLETE, RIGHT ................1.............. INCLUDES ITEMS W/#
2 EM092306 BRAKE ASSY COMPLETE, LEFT ..................1.............. INCLUDES ITEMS W/%
.......................................................................................... SEE NOTE BELOW
3 363198 OIL SEAL 1
4 363196 INNER BEARING CONE 2 IN. 1
5 383911 INNER BEARING CUP 2 IN. 1
6#% 363909 WHEEL STUD 1/2 IN. - 20 UNF PRESS IN 8
7 363239 HUB AND DRUM ASSY. 2
8 363916 OUTER BEARING CONE 1
9 363420 OUTER BEARING CUP 1
10 568326 LOAD WASHER 1 IN. T5 HP 1
11 363257 SLOTTED NUT, 1 IN. UNF 2
12 363258 COTTER PIN 3/16 IN. X 1-1/2 2
13 EM514813 RIM AND TIRE 2
14 363203 WHEEL LUG NUTS 1/2 UNF 60 CON 8
15 363199 GREASE CAP 2
16 EM104 BOLT, HEX HEAD 5/8 IN. NC X 2 IN. G5 .........4.............. REPLACES 503982
17 0401450160 WASHER, FLAT 5/8 IN. ...................................8.............. REPLACES 492602
18 EM969023 NUT, LOCK 5/8 IN. ...........................................4.............. REPLACES 492586
RIGHT AND LEFT SIDE AXLE
ASSEMBLIES ARE IDENTICAL WITH
THE EXCEPTION OF
THE BRAKE
ASSEMBLY.
