MTX60HD RAMMER • OPERATION AND PARTS MANUAL — REV. #3 (10/26/18) — PAGE 31
GUIDE CYLINDER ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 368461210 PISTON PIN 1
2 368459920 PISTON PIN PLUG 2
3 368347290 PISTON ROD 1
4 368461160 PISTON END 1
5-1 012012030 BOLT 12X30 T 1
5-2 030212300 WASHER, LOCK M12 1
6 952404790 WASHER 13306 1
7 368461260 LOWER STOPPER 1
8 368461200 BOTTOM STOPPER 1
9 368461270 MAIN SPRING 2
12 368347281 SPRING CYLINDER .........................................1................REPLACES P/N 368347280
13 368217710 FOOT PLATE 1
14 050100800 0-RING G-80 1
15 014210020 SOCKET HEAD BOLT 15X20 T 4
16 001520835 SOCKET HEAD BOLT 8X25 T 4
17 953405270 PLUG 1/4X14 13L 1
18 953405260 PACKING 1/4 (CU) 1
20 368217720 CYLINDER GUIDE 1
21 050100850 0-RING G-85 1
22 050101150 0-RING G-115 1
23 012710035 BOLT 10X35 H, SW4 4
24 368346180 ORANGE BELLOWS 1
25 368347520 BELLOWS CLAMP 131D 1
26 368461400 BAND GUIDE 131D 1
27 368347530 BELLOWS CLAMP 149D 1
28 368461410 BAND GUIDE 149D 1
29 011008040 BOLT 8X40 T 2
30 020108060 NUT M8 2
31 953405270 PLUG 1/4X14 13L 1
32 953405260 PACKING 1/4 (CU) 1
33 368118970 PROTECTION SLEEVE 1
34 366460300 OIL GAUGE ASSY. 1
35 953404670 COPPER PACKING 17X25.5X1 1
36 050200800 0-RING P-80 1
37 050101300 0-RING G-130 1
