MTX60HD RAMMER • OPERATION AND PARTS MANUAL — REV. #3 (10/26/18) — PAGE 35
FUEL TANK AND HANDLE ASSY
NO. PART NO. PART NAME QTY. REMARKS
1 368347630 SHOCK ABSORBER 2
2-1 014210020 SOCKET HEAD BOLT 10X20 T 4
2-2 033121009 TOOTHED LOCK WASHER B M10 4
3 368119572 HANDLE 1
4-1 001211020 BOLT 10X20 H 4
4-2 030210250 WASHER, LOCK M10 4
5 939010270 STOPPER RUBBER (70) 1
6 030208200 WASHER, LOCK M8 1
7 020108060 NUT M8 1
9 366350460 CAP ASSY., FUEL TANK 1
10 366120250 FUEL TANK/MTX70 1
11 022710809 NYLON NUT M8 3
11-1 011208025 BOLT 8X25 H 3
11-2 030208200 WASHER, LOCK M8 3
11-3 0401450080 WASHER, FLAT M8 3
12 952401450 WASHER, 8.5X22X3 2
13 0401450080 WASHER, FLAT M8 1
14 954406010 STRAINER #110 1
15 050250420 O-RING P42 1
16 366350110 HOLDER, FILTER .............................................1................INCLUDES ITEMS W/ $
17 001200515 BOLT 5X15 H 3
18 030205130 WASHER, LOCK M5 3
19 959328406 FUEL HOSE L=90 1
20 954406420 HOSE BAND 10.5 2
22 009110037 TAPPING SCREW 5X20 2
23 094010053 PAN HEAD SCREW 4X8 4
40 366910030 ROLLER ASSY. W/SCREW ..............................1................INCLUDES ITEMS W/#
41 # 366217170 ROLLER 2
42# 0017105020 SCREW 5X20 4
43# 022610505 FLANGE NUT M5 H 4
51 955010311 TACH/HOUR METER 1
53 955010305 CURL CORD TP22 1
54 366345620 FINISHER, METER 1
55 454010020 CLAMP TC100 5
56 954010270 CLIP AB-3N 1
57&$ 366464260 CUP, HOLDER FILTER 1
58&$ 366464270 PACKING, HOLDER FILTER 1
59$ 366900170 CUP AND PACKING SET ..................................1................INCLUDES ITEMS W/&
101 959328402 FUEL HOSE 5.5X8.5X170 1
102 0561080020 CLAMP, HOSE 4
104 16910Z4ES21 FILTER, IN-LINE FUEL 1
105 959328403 FUEL HOSE 5.5X8.5X260 1
106 954407720 TUBE, VINYL L180 1
111% 959028301 RETURN HOSE 3X6X600 1
112% 954408170 HOSE CLIP 2
113% 959021814 SPIRAL TUBE 6D-200L 1
To Next Page
