MTX60HD RAMMER • OPERATION AND PARTS MANUAL — REV. #3 (10/26/18) — PAGE 41
NO. PART NO. PART NAME QTY. REMARKS
1 12000Z0DV00 BARREL ASSY., CYLINDER ............................1................INCLUDES ITEMS W/@
2@ 12201Z0D305 GUIDE ASSY., EX VALVE (O.S.) 1
3@ 12204Z0D305 GUIDE, INLET VALVE (O.S) 1
5 12311Z0D000 COVER, HEAD T 1
6 12355Z0D000 COVER COMP A, BREATHER 1
7 12365Z0D000 COVER COMP B, BREATHER 1
8 15571Z0DV71 VALVE, OIL OUTLET 1
9 15572ZM7000 PLATE, STOPPER 1
10 15721Z0DV70 TUBE, BREATHER 1
11 90014952000 VOLT, FLANGE 6X14 (CT200) 6
12@ 91202KJ9003 OIL SEAL 20X32X6 1
13 93500030050A SCREW 3X5 1
14 9805655777 PLUG, SPARK (U16FSR-UB) 1
15 15171Z0DV00 PIPE, BREATHER 1
16 90008ZM7000 BOLT 4X10 1
HONDA GX100UKRBF ENGINE — CYLINDER BARREL ASSY.
To Next Page
