MTX60HD RAMMER • OPERATION AND PARTS MANUAL — REV. #3 (10/26/18) — PAGE 43
NO. PART NO. PART NAME QTY. REMARKS
1 11300Z0D409 COVER ASSY., CRANK CASE .........................1................INCLUDES ITEMS W/@
3 15600ZM7003 OIL FILLER CAP ASSY ....................................2................INCLUDES ITEMS W/#
4# 15625ZE1003 PACKING, OIL FILLER CAP 2
5@ 16510ZL8000 GOVERNOR ASSY. 1
9@ 16531ZE1000 SLIDER, GOVERNOR 1
10 16541Z0D000 SHAFT, GOVERNOR ARM 1
11 90121952000 FLANGE BOLT 6x25 8
12 90131ZE1000 BOLT, DRAIN PLUG 1
13@ 90451ZE1000 THRUST WASHER 6 MM 1
14 90601ZE1000 WASHER, DRAIN PLUG 1
15@ 90602ZE1000 CLIP, GOVERNOR HOLDER 1
16@ 91202KJ9003 OIL SEAL 20x32x6 1
17@ 9410106800 PLAIN WASHER 6 MM 2
18 9425108000 LOCK PIN 1
19 9430108200 KNOCK PIN 2
21@ 91001Z0DV01 BEARING, RADIAL BALL 6204 1
24 91231891003 OIL SEAL 6x11x4 1
HONDA GX100UKRBF ENGINE — CRANKCASE COVER ASSY.
