MTX60HD RAMMER • OPERATION AND PARTS MANUAL — REV. #3 (10/26/18) — PAGE 55
NO. PART NO. PART NAME QTY. REMARKS
1@ 16010Z0DV02 GASKET, METALING DIAPHRAGM 1
2@ 16011Z0DV02 GASKET, PUMP 1
3@ 16013Z0DV02 DIAPHRAGM ASSY., METALING 1
4@ 16014Z0DV02 DIAPHRAGM, PUMP 1
5@ 16018ZM3004 SCREEN, INLET 1
6@ 16019ZM3004 VALVE, INLET NEEDLE 1
7@ 16022ZM3014 PIN, METALING LEVER 1
8@ 16023Z0DV02 LEVER, METALING 1
9@ 16030ZM3004 SPRING, PUMP 1
10@ 16040Z0DV02 COVER, PUMP 1
11@ 16041Z0DV02 SCREW 1
12@ 16042Z4EV92 SPRING 1
13@ 16043Z0DV02 COVER, METALING DIAPHRAGM 1
14@ 16044Z0DV02 SCREW 1
15@ 16045Z0DV02 STOPPER, THROTTLE LEVER 1
16@ 16046Z0DV73 LEVER, THROTTLE 1
17@ 16054Z0DV02 SCREW, VALVE 1
18@ 16048Z0DV02 SPACER, THROTTLE LEVER 1
19@ 16049Z4ES12 SCREW, IDLE ADJUSTING 1
20@ 16050Z0DV02 SPRING 1
21@ 16051Z0DV02 VALVE, THROTTLE 1
22@ 16052Z0DV02 SHAFT, THROTTLE 1
23@ 16053Z0DV02 CLIP, THROTTLE SHAFT 1
24@ 16054Z0DV02 SCREW, VALVE 1
25@ 16055Z0DV02 SCREW ASSY. 5
26@ 16056Z0DV02 SPRING 1
27@ 16057Z0DV02 BALL 1
28@ 16058Z0DV72 SHAFT ASSY., CHOKE 1
29@ 16059Z0DV03 VALVE, CHOKE 1
30@ 16060Z0DV02 SCREW 1
31@ 16061Z0DV02 SEAL, DUST 2
32 16100Z4ES15 CARBURETOR, ASSY., (HAD 201C) ................1................INCLUDES ITEMS W/ @
33 16211Z0DV00 INSULATOR, CARBURETOR 1
34 16212Z0DV00 PACKING, INSULATOR 1
35 16213Z4ES10 INSULATOR B, CARBURETOR 1
36 16214Z0DV01 PACKING B, INSULATOR 1
37 16215Z0DV00 PLATE, INSULATOR 1
38 16221Z0DV00 PACKING, CARBURETOR 2
39 950014500350M HOSE, FUEL 4.5X270 1
40 H950024085008 CLAMP, TUBE 2
42 950033600110M TUBE, VINYL 11X13X1M 1
43 16552896650 COLLAR, LEVER 1
HONDA GX100UKRBF ENGINE — CARBURETOR ASSY. (S/N T-3423 & BELOW)
