MTX60HD RAMMER • OPERATION AND PARTS MANUAL — REV. #3 (10/26/18) — PAGE 65
NO. PART NO. PART NAME QTY. REMARKS
3 16555Z0DV00 GOVERNOR ROD 1
4 16561Z0DV00 GOVERNOR SPRING 1
5 16562Z4ES10 SPRING, THROTTLE RETURN 1
6@ 16594883010 HOLDER, WIRE 1
8 90014952000 BOLT, FLANGE 6X14 (CT200) 2
9 90015ZE5010 BOLT, GOVERNOR ARM 1
10@ 90605230000 CIR CLIP 1
11@ 92301050220A BOLT 5X20 1
12@ 0043504060 SCREW 4X6 1
15 9405006000 FLANGE NUT 6MM 1
17 16550Z0DV01 GOVERNOR ARM 1
19 16500Z4ES30 CONTROL ASSY ..............................................1................INCLUDES ITEMS W/@
20@ 9400105000 NUT M5 2
HONDA GX100UKRBF ENGINE — CONTROL ASSY.
