MULTIQUIP QP3TH - Pump Specifications

QP3TH TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #9 (02/20/18) — PAGE 11
Table 1. Specifications (Pump)
Pump
Model QP3TH
Type Trash Pump
Suction 3.0 in. (76 mm.)
Discharge Size 3.0 in. (76 mm.)
Maximum Pumping Capacity
396 gallons/minute
(1,500 liters/minute)
Max. Solids Diameter 1.50 in. (38 mm)
Maximum Sunction Lift 25 ft. (7.6 m)
Max. Head 95 ft. (29.0 m)
Max. Pressure 41 psi (283 kPa)
Dry Net Weight
142 lbs. (64.5 Kg.)
SPECIFICATIONS (PUMP)
Figure 1. QP3TH Dimensions
22.0 IN.
(559 MM)
20.6 IN.
(522 MM)
27.9 IN.
(708 MM)
